The EV-100 tiller pilot for tiller steered boats with displacement up to 6,000 kg. The Evolution autopilot systems perceive their environment and instantly calculate and evolve steering commands to maximize performance. The result is precise and confident course keeping, regardless of vessel speed or sea conditions – Evolution autopilots steer so accurately they can save fuel and get you to your destination faster. Pack Contains : p70s Control Head, EV1 Sensor Core, ACU-100 Drive interface, Tiller Drive and Evolution Cabling Kit.
p70s and 70Rs Features
Raymarine p70s and p70Rs Autopilot Control Heads
The Raymarine p70s autopilot control head is a push-button operation controller designed primarily for sailboats, while the Raymarine p70Rs autopilot control head, with its combination of push-buttons and rotary control dial, is aimed at powered craft.
Key features:
3.5” super bright oversized LCD for maximum visibility
All weather, low power, optically bonded display technology delivers brighter colours, sharper contrast, and a wide viewing angle
Button or rotary control options for sail and power applications
Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer
Display the pilot information in different formats with automatic 3-step setupfor leisure, cruising and performance
Simple system and group dimming / illumination
Easy to use Lighthouse user interface with sculpted rubber keypad for precise operation in all conditions
SeaTalkng networking for seamless connectivity to Raymarine systems and NMEA2000* networks
New glass bridge industrial design compliments Raymarine eS and gS Series multifunction displays
Supplied with both black (eS Series style) & (e Series style) gunmetal bezels and protective suncover
The EV Sensor Core
At the centre of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-to-install housing.
Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.
EV Sensor Core Benefits
Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change.
Flexible installation options. Mount above or below deck.
Simple SeaTalkng connectivity to the control head and ACU.
Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions.
Auto-compensation for on board magnetic fields and reliable heading accuracy in the northern and southern extremes.
Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays.
Autopilot Control Unit (ACU)
The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering type:
Supported Drives
ACU-100 Wheel, tiller and 0.5 ltr Hydraulic
