The GIGAVAC GX14BA contactor is a 400 ampere single-pole single-throw (SPST) normally open (NO) high voltage high current relay capable of breaking current flows up to 900 volts..
Mechanically rated for over 1,000,000 cycles, this hermetically sealed contactor features built-in coil suppression and IP67 environmental rating.
The coil operates on 32-64vdc with a 1.1 amp close but a small 60 ma holding current.
UL 1604 listed for Classes I, II, and III.
GX Contactors can switch DC loads from 12 to 800VDC. These small RoHS compliant hermetically sealed contactors can be mounted in any position, can be used in nearly any harsh environment including under water and at temperatures from –55°C to 85°C. GX relays have an inbuilt coil economiser that reduces coil current significantly when engaged.
Normally Open (NO) contact configuration.
2 wire coil, 48V.
12V – 800VDC switching
48V dual coil design (60mA ON current), economiser.
Up to 650A break current
Sealed contactor, can be used in all environments.
Made in the USA.
